PPR FITTINGS

Product Features
(1) High Temperature Resistance: the maximum sustained working temperature is up to 70 Degrees Celsius, the maximum transient temperature is up to 95 Degrees Celsius.

Inquiry

Detail

Product Features

(1) High Temperature Resistance: the maximum sustained working temperature is up to 70 Degrees Celsius, the maximum transient temperature is up to 95 Degrees Celsius.
(2) Heat Preservation: low thermal conductivity which is only 1/1500 of brass pipe, and 1/250 of steel pipe. Non-toxic: no heavy metal additives would not be covered with dirty or contaminated by bacterium.
(3) Corrosion Resistant: resist chemical matters or electron chemical corrosion.
(4) Lower Installation Costs: light weight and ease of installation can reduce installation costs by as much as 50% over metal piping system.
(5) Higher Flow Capacity: smooth interior walls result in lower pressure loss and higher volume than metal pipes.
(6) Long Life: more than 50 years under normal conditions.
(7) Recycled and Environment-friendly.

ppr fittings 7

ppr fittings 8 ppr fittings 9

Product Parameters

Items	ppr reducing tee
material	polypropylene random
size	25×20 – 110×90 mm
color	white,green,gray
connection	hot melting
pressure	1.25MPa,1.6MPa,2.0MPa,2.5MPa
standard	DIN8077, DIN8078 ,ISO15874
Certification	ISO14001,OHSAS18001,ISO9001,CE,GOST

SPECIFICATION (INCH)	SPECIFICATION (MM)	D	L	Z
SPECIFICATION (INCH)	SPECIFICATION (MM)	D	L	Z	3/4″ x 1/2″	25 x 20	34.8	30.5	18.5
1″ x 1/2″	32 x 20	42.2	32.5	20.5
1″ x 3/4″	32 x 25	42.2	34.5	20.5
1 1/4″ x 1/2″	40 x 20	52.5	34.5	22.5
1 1/4″ x 3/4″	40 x 25	52.5	36.5	22.5
1 1/4″ x 1″	40 x 32	52.5	39.5	22.5
1 1/2″ x 1/2″	50 x 20	65.3	37.5	25.5
1 1/2″ x 3/4″	50 x 25	65.3	39.5	25.5
1 1/2″ x 1″	50 x 32	65.3	39.5	25.5
1 1/2″ x 1 1/4″	50 x 40	65.3	47.5	25.5
1 1/4″ x 1/2″	63 x 20	83	41.5	29.5
1 1/4″ x 3/4″	63 x 25	83	43.5	29.5
1 1/4″ x 1″	63 x 32	83	47.5	29.5
1 1/4″ x 1 1/4″	63 x 40	83	51.5	29.5
1 1/4″ x 1 1/2″	63 x 50	83	56.5	32.5
2 1/2″ x 3/4″	75 x 25	100	48.5	32.5
2 1/2″ x 1″	75 x 32	100	50.5	32.5
2 1/2″ x 1 1/4″	75 x 40	100	53.5	32.5
2 1/2″ x 1 1/2″	75 x 50	100	58.05	32.5
2 1/2″ x 1 1/4″	75 x 63	100	64.5	36.5
3″ x 1 1/4″	90 x 40	118	57.5	36.5
3″ x 1 1/2″	90 x 50	118	62.5	36.5
3″ x 1 1/4″	90 x 63	118	69.5	36.5
3″ x 2 1/2″	90 x 75	118	75.5	36.5
4″ x 1 1/2″	110 x 50	145	70.5	43.5
4″ x 1 1/4″	110 x 63	145	76.5	43.5
4″ x 2 1/2″	110 x 75	145	82.5	43.5
4″ x 3″	110 x 90	145	90.5	43.5
