Product Features
Cresline PVC Well Casing Pipe is produced using PVC 1120 polyvinyl chloride material to meet or exceed ASTM F480 standards and is NSF-approved for well casing use. SDR-21, SDR-26, and Schedule 40 sizes are NSF-approved for drinking water use. PVC Well Casing Pipe is white in color and is available in beveled solvent weld SDR-26, SDR-21, SDR-17, and Schedule 40 sizing.
| RESISTANCE TO HYDRAULIC COLLAPSE PRESSURE DATA (RHCP) IN PSI AND FEET OF WATER |
||
| PIPE DESCRIPTION | PSI | FEET |
| SDR-26 (ALL SIZES) | 57 | 132 |
| SDR-21 (ALL SIZES) | 111 | 255 |
| SDR-17 (ALL SIZES) | 215 | 495 |
| 2″ SCH-40 | 291 | 672 |
| 4″ SCH-40 | 152 | 350 |
| 4%” SCH-40 | 130 | 299 |
| 5″ SCH-40 | 102 | 235 |
| 6″ SCH-40 | 74 | 170 |
| 8″ SCH-40 | 57 | 132 |
| 10″ SCH-40 | 39 | 90 |
| 12″ SCH-40 | 32 | 74 |
| 16″ SCH-40 | 30 | 69 |
Typical applications for PVC Well Casing Pipe include:
Well casing
Well liners
Pressure systems
Irrigation
Submersible pumps
Jet pumps
